Android 14 GMS Keyboard 4′ Touch Screen IP67 Mobile Computer With Zebra Scan Engine 64GB ROM + 4GB RAM GPS NFC OTG WIFI Bluetooth
Android 14 barcode scanner keypad pda Keypoint:
- Latest Android 14 with GMS cerfified
- 32GB + 2GB (64GB + 4GB optional)
- Professional barcode scan engine and zebra/honeywell scan engine optional
- 5000mAh large capacity battery
- LTE 4G,3G,2G,WIFI, bluetooth 5.0, NFC approval
- 4inch touch screen with keyboard
- Support GPS,AGPS, Glonass, BDS navigation
- IP67 protection grade
| Product Name | Android 14 GMS Keyboard 4′ Touch Screen IP67 Mobile Computer With Zebra Scan Engine 64GB ROM + 4GB RAM GPS NFC OTG WIFI Bluetooth |
|
Model |
GJYF7 |
|
System Configuratio Specifications |
|
|
Processor |
MT6762V/WB(Octa-core，4*A53 2.0GHz) |
|
Operating System |
Android 14 |
|
Memory |
32 GB ROM+2 GB RAM(Standard) (64GB + 4GB optional) |
|
Expansion Slot |
Micro SD card (Up to 64GB SDHC） |
|
Display |
4.0″，WVGA，800*480, IPS |
|
Touch Panel |
Capacitive touch panel |
|
Front Camera |
N/A |
|
Rear Camera |
5MP, AF, with flash LED |
|
Touch Glas |
Tempered glass |
|
Keypad |
22 physical keyboard keys on the front 1 power key, 2 scan keys on the side; |
|
Battery Capacity |
5000mAh removable lithium polymer battery |
|
Fast charge |
5V/2A |
|
Speaker |
3413 big speaker |
|
Prompt |
Vibration prompt /LED prompt/audio prompt |
|
Vibration |
Built-in vibration motor |
|
Sensor |
G-sensor |
|
Communication Transmission |
|
|
Wireless WAN (Network frequency） |
GSM(B3/B5/B8)TD-SCDMA：B34/B39 |
|
Wireless WAN (Data Service） |
GSM/TD-SCDMA/WCDMA/TDD-LTE/FDD-LTE |
|
Wireless LAN |
Wi-Fi 802.11 a/b/g/n/ac/k/v/r(Dual bands： 2.4GHz+5GHz) |
|
Bluetooth |
Bluetooth 5.0 |
|
GPS |
Support GPS/AGPS/Glonass/BDS |
|
1D/2D Barcode Scanning |
|
|
Scan engine |
Professional scanner SE6100-2D （developed together with Zebra） |
|
Optical resolution |
1280*800 Pixes |
|
Scan precision |
≥3mil , Code 39/128 |
|
Scan Angles |
Tilt:360°，Pitch:±45°，Skew:±60° |
|
Laser Safety Grade |
Class II |
|
NFC (Optional) |
|
|
Frequency |
13.56 MHz |
|
Reading Distance |
Within 2cm |
|
Protocol |
ISO14443A/ISO14443B |
|
Special feature |
Support contactless CPU card, support 2 generation ID card read |
|
User Environment |
|
|
Operating Temp. |
-20~55° |
|
Storage Temp. |
-40~60° |
|
Humidity |
0~95% |
|
Drop Specification |
Marble 2M ，Concrete 1.5M |
|
IP Grade |
IP67 |
|
ESD |
±12 KV air discharge；±8 KV conductive discharge |
|
Input / Output Ports |
|
|
USB Port |
1 PCS，Type-C USB waterproof port |
|
Charger Port |
1 PCS, Type-C USB waterproof port |
|
OTG |
Support |
|
Develop Tools |
|
|
Developing Tool |
Android SDK |
|
Supported language |
Java |
|
Accessories |
|
|
Standard |
Power adapter、USB cable、Battery， Lanyard，tempered glass screen protector |
|
Optional |
Desktop charger (Optional) |
|
Mechanical Parameter |
|
|
Dimension(LxWxD) |
159mm*70.8mm*17.85mm |
|
Weight |
260g（Battery included ） |
